جديد جرافة ذات عجلات SDLG L958HEV Garantie 5 ani

SDLG L958HEV Electric Wheel Loader
Operating weight (kg): 19,700
Bucket capacity (m³): 3.2
Rated load (kg): 5,800
Rated power (kW): 231
Features

The L958HEV is equipped with reliable electric battery packs, delivering high power, zero emissions, and low noise levels.

The dual-motor, four-output transmission system ensures smooth gear shifting and reliable power delivery.

Standard high-speed, high-power-density motors offer energy savings and efficiency.

The intelligent control system automatically adjusts power delivery based on load, speed, and other conditions.

Integrated regenerative braking technology and an automatic start/stop function extend operating time.

Quick coupler, 3-function valve, emergency steering, and single-lever electronic control.

The intelligent thermal management system keeps all systems safe, even in extreme environments.

Work modes: Loading, Leveling, Stacking, and ECO.

Technical Specifications:

Standard bucket capacity (m³) 3.2 (4.19 yd³)
Rated load (kg) 5,800 (12,787 lbs)
Operating weight (kg) 19,700 (43,431 lbs)
Battery type LFP
Battery capacity (kWh) 350
Voltage (V) 579.6
DC charging capacity (kWh) 240
Estimated runtime (depending on application, h) 5–8
Motor type PMSM
Rated power (kW) 231 (310 hp)
Speed ​​F1/R1 (km/h) 0–15 (0–9.3 mph)
Speed ​​F2 (km/h) 0–40 (0–24.9 mph)
Breakout force (kN) 150 (33,721 lbf)
Tire size 23.5–25
Transport dimensions (L × W × H, mm) 8,850 × 3,016 × 3,460
Wheelbase (mm) 3,400 (11′ 1.9″)
Ground clearance (mm) 435 (1′ 5.1″)
Reach at maximum height (mm) 1,340 (4′ 4.8″)
Dump angle (°) 45
Bucket hinge pin height (mm) 4,145 (13′ 7.2″)
Dump height (mm) 2,880 (9′ 5.4″)
Bucket tilt angle at ground level (°) 42
Wheel track (mm) 2,250 (7′ 4.6″)
Articulation angle (°) 36
Turning radius over bucket (mm) 7,310 (23′ 11.8″)


Also we have bigger wheel loaders:
SDLG L968HEV -Electric- 22,3 tons ;bucket: 3-6 m3
SDLG L970HHB - Hibrid- Diesel+Electric- 22,7 tons ; bucket 3-6 m3
SDLG L980HEV -Electric-26,6 tons; bucket 3,6-7 m3
